General information:
– Built by Voith 2008 and Valmet 1999
– Speed of the paper machine 1.000 m/min
– White top from 115 – 190 gr/m2
– Available September 2026
Composed by:
– 7 Vac Rolls useful width paper 2.770 mm and diameter 1.250 mm CC bearings 3.575 mm
– 10 dryers on cast Iron Voith face width 3.030 mm and useful width paper 2.850 mm diameter 1.500 mm and press work 8 bars
– 35 dryers on cast Iron Valmet face width 2.985 mm and useful width paper 2.850 mm diameter 1.500 mm and press work 8 bars
– Rolls diameter 268 mm and face width 3.100 mm
– Kuster calendar face width 2.850 mm and diameter 660 mm and kuster roll 513 mm
– Doctors, stabilizers, tensor and guide
– Not included frames and hood
