Headboxes

Head Box VAS slice width 2.700 mm

Head Box VAS slice width 2.700 mm

General information: - Built by VAS year 1997- Slice width 2.700 mm- Flow maximum 40.000 lpm- Speed maximum 800 m/min at 50 gr/m2- Built on stainless steel- Included: duo shake and fan pump- Condition very good and dismantled Head Box VAS slice width 2.700 mm

BELOIT STRATAFLOW Pressurized Head Box slice width 4.600 mm

BELOIT STRATAFLOW Pressurized Head Box slice width 4.600 mm

General information: - Slice width: 4600 mm - Paper width at pope: 4300 mm - Capacity: 300 Tpd - Paper gramage: 90 to 200gr/m2 - Twin layers - Model: Concept III - Wire width: 4750 mm - Breast rolls Ø: 728mm - Left hand drive - Was working at 600 m/min BELOIT...

Head Box BLACK CLAWSON slice width 4.850 mm

Head Box BLACK CLAWSON slice width 4.850 mm

General information: - Slice width 4.850 mm - Flow from 25.000 to 40.000 l/min - Basis weight 105 – 230 gr/m2 - Speed from 530 – 750 m/min - Head box consistency 1,0 – 1,5 % - Hand of the machine left hand - Trim width at reel 4.560 mm - Wire width 4.953 mm - Year...

Close Head Box BRUDERHAUS slice width 1.750 mm

Close Head Box BRUDERHAUS slice width 1.750 mm

General information: - Built on stainless steel - Manufacturer Bruderhaus - Slice width 1.750 mm - 2 deflocculated rolls diameter 140 mm - Diameter manifold 170 mm - Papers from 30 – 200 gsm Close Head Box BRUDERHAUS slice width 1.750 mm

Crescent former Head box slice width 2.850 mm

Crescent former Head box slice width 2.850 mm

General information: - Installed new in 2004 and start up in 2005 - Width after rewinder 2.750 mm - Capacity 80-100 Tpd - Machine Crescent former with twin jets headbox - Built by PMT Stainless twin jet headbox slice width 2.850 mm, with adjust of the slice, for a...

HEAD BOX slice width 2.380 mm

HEAD BOX slice width 2.380 mm

General information: - Installed new 1998 - Built on stainless steel - Slice width 2.380 mm - Flow maximum 10.300 l/min - Flow minimum 4.800 l/min - 2 x defloculator rolls diameter 270 mm holes 20 mm - Dismantled and stored out side - Manual slice regulation...
